Danfoss ECL Comfort 310 Installation Guide

InstallationGuideECLComfort210/310,applicationA214/A314
A214.2A214.3

A214.2:Heatingwithducttemperaturecontrol
A214.3:Heatingwithroomtemperaturecontrol





















 
TypicalA214.2application:
S 4
P 2
S 5
M1
S 6
X3
S 3
S 7
F1
S 8
S 8
S 8
S 1
Da nfos s 87 H2118 .11
ECL 210 / 310
A1



Listofcomponents:
ECL210/310
ElectroniccontrollerECLComfort210or310
S1
Outdoortemperaturesensor
S2
(Optional)Compensationtemperaturesensor(not
illustrated)
S3
Flowtemperaturesensor
S4Ducttemperaturesensor
S5
(Optional)Returntemperaturesensor
S6
(Optional)Frosttemperaturesensor
S7
(Optional)Frostthermostat
S8
(Optional)Firethermostat
F1
Fan(ON/OFF)
P2
Damper(ON/OFF)
X3
Circulationpump(ON/OFF)
M1
Motorizedcontrolvalve,heating(3-pointcontrolled)
A1
Alarm



