Danfoss ECL Comfort 310

InstallationGuideECLComfort210/310,applicationA214/A314
TypicalA214.3application:
ECL 210 / 310
S 3
P 2
S 5
M1
S 6
X3
S 7
F1
S 8
S 8
S 8
S 1
Da nfos s 87 H212 0.11
A1
S 4



Listofcomponents:
ECL210/310
ElectroniccontrollerECLComfort210or310
S1
Outdoortemperaturesensor
S2
(Optional)Compensationtemperaturesensor(not
illustrated)
S3Ducttemperaturesensor
S4
Roomtemperaturesensor*
S5
(Optional)Returntemperaturesensor
S6
(Optional)Frosttemperaturesensor
S7
(Optional)Frostthermostat
S8
(Optional)Firethermostat
F1
Fan(ON/OFF)
P2
Damper(ON/OFF)
X3
Circulationpump(ON/OFF)
M1
Motorizedcontrolvalve,heating(3-pointcontrolled)
A1
Alarm
*Alternative:ECA30



