Danfoss ECL Comfort 310 Installation Guide

InstallationGuideECLComfort210/310,applicationA214/A314
A214.4

Heating/coolingwithairducttemperaturecontrol
































 
TypicalA214.4application:
P 2
F1
S 4
S 1
Da nfos s 87 H212 2.11
S 5
M1
X3
M2
ECL 210 / 310
A1
S 6
S 7
S 8
S 8
S 8
S 3



Listofcomponents:
ECL210/310
ElectroniccontrollerECLComfort210or310
S1
Outdoortemperaturesensor
S2
(Optional)Compensationtemperaturesensor(not
illustrated)
S3
Heatingtemperaturesensor
S4
Airducttemperaturesensor
S5
(Optional)Returntemperaturesensor
S6
(Optional)Frosttemperaturesensor
S7
(Optional)Frostthermostat
S8
(Optional)Firethermostat
F1
Fan(ON/OFF)
P2
Damper(ON/OFF)
X3
Circulationpump,heating(ON/OFF)
M1
Motorizedcontrolvalve,heating(3-point
controlled)
M2
Motorizedcontrolvalve,cooling(3-pointcontrolled)
A1
Alarm



