InstallationGuideECLComfort210/310,applicationA214/A314
A314.2

Heatingand(passive)coolingwithroomtemperaturecontrol






























 
TypicalA314.2application:
S 3
M2
S 5
M1
X3
S 4
A
F1
ECL 310
A1
S 6
S 7
+ ECA 32
S 2
S 1
Da nfos s 87 H212 7.1 2
P 2
S 8
S 8
S 8



Listofcomponents:
ECL310
ElectroniccontrollerECLComfort310
ECA32
Built-inextensionmodule
S1
Outdoortemperaturesensor
S2
(Optional)Compensationtemperaturesensor
S3Ducttemperaturesensor
S4
Roomtemperaturesensor*
S5
(Optional)Returntemperaturesensor
S6
(Optional)Frosttemperaturesensor
S7
(Optional)Frostthermostat
S8
(Optional)Firethermostat
F1
Fan(ON/OFF)
P2
Damper(ON/OFF)
X3
Circulationpump,heating(ON/OFF)
M1
Motorizedcontrolvalve,heating(3-pointcontrolled)
M2
Motorizeddamper(0-10voltcontrolled)
A1
Alarm
*Alternative:ECA30




