User Guide FP720 Two Channel Heating Timer
Danfoss Heating
VUSUH102 05/2019
3
4 Timer Schedule Setup
• Press button to access schedule setup
• Press CH button to select between SET CH1 or SET HW schedule (CH1 and CH2 if set for two heating zones),
press OK to conrm
Example below for 5/2 day setup, 2 periods
Mo. Tu. We. Th. Fr. ashing
Press OK to accept or right arrow to select Sa. Su.
Period 1:
1. Use < or > to select ON hour, press OK to conrm
2. Use < or > to select ON minute, press OK to conrm
3. Use < or > to select OFF hour, press OK to conrm
4. Use < or > to select OFF minute, press OK to conrm
Repeat 1 to 4 above for period 2
Sa. Su. Now showing in display.
Period 1
1. Use < or > to select ON hour, press OK to conrm
2. Use < or > to select ON minute, press OK to conrm
3. Use < or > to select OFF hour, press OK to conrm
4. Use < or > to select OFF minute, press OK to conrm
Display returns to home screen and schedule is set.
Where FP720 is set for 7day schedule, option will be given to select each day separately. In 24hr mode, option
will only be given to select Mo. to Su. together. See parameter P1.
Where FP720 is set for 3 periods, options will be given to select period 3 times. In 1 period mode, option will only
be given for one time period. See parameter P2.
A default program provides timer control if the user does not create own programs:
5/2 or 7 day – 3 Periods selected
Days Event 1 - On Event 2 - O Event 3 - On Event 4 - O Event 5 - On Event 6 - O
Start time Start time Start time Start time Start time Start time
Mon - Fri 6:30 8:30 11:30 13:30 16:30 22:30
Sat - Sun 7:30 9:30 11:30 13:30 16:30 22:30
* Floor temperature control mode.
For 24hr mode, default schedule follows Mo. to Fr. times above.
For 2 periods setup, default event times 1, 2, 5 & 6 are used. For 1 period setup, default event times 1 & 6 are
used.
Note: if parameter P1 or P2 are changed schedule will default to times above and user selected times will need to be
reset.
