Force
Single Coil
(05
HEX
)
Description
Forces a single coil (0X reference) to either
ON or OFF. When broadcast, the function
forces the same coil references in all attached
slaves.
Query
The query message specifies the coil
reference to be forced. Coils are addressed
starting at zero. Coil 1 is addressed as 0.
Force Data = 00 00
HEX
(OFF) or FF 00
HEX
(ON).
Example of a request to set coil 1 (addressed as 0) from slave device 01.
Field Name Example (HEX)
Slave Address 01
Function 05
Coil Address HI 00
Coil Address LO 00
Force Data HI FF
Force Data LO 00
Error Check (CRC)
Response
The normal response is an echo of the query,
returned after the coil state has been forced.
Field Name Example (HEX)
Slave Address 01
Function 05
Force Data HI FF
Force Data LO 00
Quantity of Coils HI 00
Quantity of Coils LO 0A
Error Check (CRC)
