29
VLT is a registered Danfoss trade mark MG.10.P2.22
Preset
Single
Register
(06
HEX
)
Description
Presets a value into a single holding register
(4x reference). When broadcast, the function
presets the same register reference in all
attached slaves.
Query
The query message specifies the register
reference to be preset. Registers are
addressed starting at zero. Register 1 is
addressed as 0.
Example of a request to preset register 40002 to 00 03
HEX
in slave device 01.
Field Name Example (HEX)
Slave Address 01
Function 06
Register Address HI 00
Register Address LO 01
Preset Data HI 00
Preset Data LO 03
Error Check (CRC) --
Response
The normal response is an echo of the query,
returned after the register contents have been
passed.
Field Name Example (HEX)
Slave Address 01
Function 06
Register Address HI 00
Register Address LO 01
Preset Data HI 00
Preset Data LO 03
Error Check (CRC) --
APPENDIX A
