VLT Modbus RTU Option Card
6-Pin Connector
to VLT Terminals
pin 1
Mounting Hole
LEDs
Baud Rate and Parity
8-Input Dip Switch
3-Pin
RS-485 Connector
Mounting Hole
Address and Termination
9-Input Dip Switch
pin 1
pin 1
pin 1
pin 1
pin 1
pin 9 (termination)
