Service guide | Disassembling and assembling PAH 50-100
2
180R9098 | 521B1072 | DKCFN.PI.011.NC5.02 | 06.2017
NOTE: If the pump is disassembled within the warranty period, the pump is no longer covered
by the warranty.
Introduction
Table of Contents 1. Disassembling the pump ................................................................................................................... 3
2. Inspection .............................................................................................................................................. 7
2.1. Port plate and thrust plate ................................................................................................................. 7
2.2. Pistons .................................................................................................................................................... 7
2.3. Cylinder barrel ..................................................................................................................................... 8
2.4. Housing .................................................................................................................................................. 8
2.5. Swash plate .......................................................................................................................................... 8
3. Assembling ........................................................................................................................................... 9
4. Service kit list for PAH 50-100.......................................................................................................... 14
5. Exploded view PAH 50-100 .............................................................................................................. 15
This document covers the instructions for
disassembling and assembling the axial piston
pumps PAH 50 -100
