Danfoss PAH Series - Spare Parts List for PAH 4-6.3

Parts list | PAH 2/4/6.3/10 and 12.5
54
180R9379 | AQ188686503004en-000801 | PAH 2-12.5 } 07.2022
180B4100 - Screw & Seal set (PAH 2-6.3) 180B4112 - Cylinder barrel set (PAH 2-6.3) 180B4101 - Valve plate set (PAH 2-6.3) 180B4111 - Piston set (PAH / 4-6.3) 180B4303 - Swash plate set (PAH 4) 180B4304 - Swash plate set (PAH 6.3) 180Z0235 - Tool set
Pos. Qnt. Designation Material
- 1 Shaft bush, torpedo - X
- 1 Press bush - X
1 1 Housing AISI 304 / PEEK
2 1 Pin AISI 316 X
5 4 Screw AISI 316 X
31 1 Swash plate AISI 431 X X
32 1 Screw AISI 304 X X
33 1 Washer AISI 304 X X
34 1 Pin AISI 316 X X
61 1 Cylinder barrel AISI 431 / PEEK X
62 1 Spring AISI 304 X
63 1 Spring guide PEEK X
64 1 Retainer ball AISI 431 X
65 1 Retainer plate AISI 431 X
66 5 Piston AISI 431 / PEEK X
67 1 Key AISI 316Ti X
91 1 Port plate AISI 304 / PEEK X
92 1 Valve plate AISI 431 X
93 5 Back up ring PTFE X X
94 5 O-ring NBR X X
121 1 Port ange AISI 304 / PEEK
122 1 O-ring NBR X
123 1 O-ring NBR X
124 1 Shaft seal AISI 304 / NBR X
125 1 End cover AISI 304
126 1 Pin AISI 316 X
127 2 Screw AISI 304 X
130 1 Usit-ring AISI 304 / NBR X
136 2 O-ring NBR X
- 1 Service instruction (180R9094) - X X X X X X
*
FFKM sealing material
3. Spare parts list for
PAH 4-6.3
