Estimated usage of memory and communication resources (continued)
Description IX012-010 IX024-010 OX012-010 OX024-010 IOX012-010 IOX024-20
RAM usage on
MC050-010,
MC050-020
1% 1% 1% 2% 1% 2%
RAM usage on
MC050-055
1% 1% 1% 2% 1% 0%
ROM usage on
MC012-XXX
8% 11% 12% 18% 10% 19%
ROM usage on
MC024-010
8% 11% 12% 18% 10% 20%
ROM usage on
MC050-010,
MC050-020
3% 4% 4% 6% 3% 8%
ROM usage on
MC050-055
3% 4% 4% 6% 3% 8%
Technical Information
PLUS+1® MC0XX-1XX Controller Family
Controller Area Network (CAN)
©
Danfoss | April 2018 L1321895 | BC00000227en-US0401 | 19
