Termix VVX-IV - 7 Series DS Fully insulated
Expansion tank
Double check valve
Heat Exchanger
The heat exchanger is produced in acid-resistant, stainless steel
38
see diagram
2B
see diagram
Fill/drain valve
Air vent, manual secondary side
Air vent, manual
Primary side.
48
see diagram
A B
see diagram
20 48
see diagram
