4
TPOne-RF
ErP Class
The products represented within this document are classied according
to, and allow completion of, the Energy Related Product (ErP) Directive
System Package che and the ErP system data label. ErP Labelling
obligation is applicable from 26th September 2015.
ERP Class Product Function and ErP Description
Additional
eciency
gain
IV
TPI Room Thermostat, for use with on/o
output heaters
An electronic room thermostat that controls
both thermostat cycle rate and in-cycle on/
o ratio of the heater proportional to room
temperature. TPI control strategy reduces
mean water temperature, improves room
temperature control accuracy and enhances
system eciency.
2%
Specications TPOne-RF RX1-S V2
Operating Voltage
2.5 - 3VDC
(2x AA batteries)
230Vac, 50/60Hz
Output relay - Volt Free
Setting temperature range 5-35°C -
Operating temperature range 0-45°C 0 - 40°C
Switch rating - 3A (1) at 230Vac
Switch type - 1 x SPDT Type 1B
Battery lifetime Min. 2 years
IP rating IP20 IP30
On/o control Yes -
Chrono-proportional control Yes -
Operating mode Heating -
Construction EN 60730-2-9, EN 60730-2-7
Pollution degree rating Degree 2
Rated impulse voltage - 4 kV
Ball pressure test 75°C
Dimensions (mm) H67 x W154 x D30 H84 x W84 x D28
Software Classication A
Operating Frequency 433.100-434.750 MHz
Battery back up time 2 hours
Maximum radio-frequency power
transmitted
10 dBm
Installation Instructions
