Danfoss TS715 Si User Manual

8
DANFOSS RANDALL
TS715-Si
MAINS
NL
NL
The existing wallplate may be used when replacing the following, but the wiring must b
e
between L & COM terminals of wallplate.
ACL LS111, LS711, LP111 & LP711 N L
DRAYTON TEMPUS ONE & TEMPUS TWO N L
LANDIS & GYR RWB3 N L
LANDIS & GYR RWB30 N L
The TS75/TS15 wallplate must be used to replace the existing wallplate when replacing t
h
age systems,  t wire link between terminal 1 & L of wallplate.
GRASSLIN 45, 45A, 45E 2 1
HONEYWELL ST6100 N L
HORSTMANN 423 PEARL, EMERALD & TOPAZ N L
HORSTMANN KMK2A YMK2 3 4
HORSTMANN 425 CORONET N L
DANFOSS RANDALL 911 N L
DANFOSS RANDALL 103, 103E, 103E5 & 103E7 5 6
RANDALL 3020 1,7 6
DANFOSS RANDALL SET1 N L
RANDALL TSR2 3 2
PEGLER SUNVIC SP20 & SP25/30 N L
POTTERTON MYSON EP4001 N L
WIRING CONVERSIONS, (applies only to 230 volt models)
Wiring conversions for other timeswitches which can be replaced with the
Danfoss TS715-Si, refer to the second part of the table. If in any doubt, please
contact our Technical Services Department before proceeding with the
replacement.

Danfoss TS715 Si Specifications

General

Brand	Danfoss
Model	TS715 Si
Category	Timer
Language	English
