PNU # Parameterdescription Factory setting 4-setup Conv.
index
Data
type
302 Digital input, term. 18 Start Yes 0 5
303 Digital input, term. 19 Reversing Yes 0 5
304 Digital input, term. 27
Reset and coast
inverse
Yes 0 5
305 Digital input, term. 29 Jog Yes 0 5
307 Digital input, term. 33 No function Yes 0 5
308 Term. 53, analogue input voltage Reference Yes 0 5
309 Term. 53, min scaling 0.0 V Yes -1 6
310 Term. 53, max scaling 10.0 V Yes -1 6
314 Term. 60, analogue input current No function Yes 0 5
315 Term. 60, min scaling 0.0 mA Yes -4 6
316 Term. 60, max scaling 20.0 mA Yes -4 6
317 Time out 10 sec. Yes -1 5
318 Function after timeout No function Yes 0 5
319 Term. 42, analogue output
0-I
MAX
= 0-20 mA
Yes 0 5
323 Relay output Control ready Yes 0 5
327 Pulse ref./FB 5000 Hz Yes 0 7
341 Term. 46 digital output Control ready Yes 0 5
342 Term. 46 Max. pulse output 5000 Hz Yes 0 6
343 Precise stop function Normal ramp stop Yes 0 5
344 Counter value 100000 pulses Yes 0 7
349 Speed comp delay 10 ms Yes -3 6
4-Setup:
'Yes' means that the parameter can be programmed
individually in each of the four Setups, i.e. one single
parameter can have four different data values. 'No'
means that the data value will be the same in all Set-
ups.
Conversion index:
This number refers to a conversion figure to be used
when writing or reading via serial communication with
a frequency converter.
See Data character in Serial communication in the VLT
2800 Design Guide.
Data type:
Data type shows the type and length of the telegram.
Data type Description
3 Integer 16
4 Integer 32
5 Unsigned 8
6 Unsigned 16
7 Unsigned 32
9 Text string
VLT
®
2800 Series
96 MG.27.A2.02 - VLT
®
is a registered Danfoss trademark
