FCM 300 / FCD 300 / VLT
®
2800 / DP V1 PROFIBUS
is still possible via the terminals, depend i ng on how
the parameters 502-508 have been programmed.
953 Warning parameter 1
(WARN. PARA)
Value:
Read only
Function:
In this parameter it is possible to read o ut w arning
messages via standard bus o r Profibus. This
parameter is not available via LCP, but the warning
message can be se en by choosing Com warning
word as display readout. A bit is assigned to
every warning (see the following list).
Bit Bit = "1" when:
0 LSB Connection with DP-master is not ok
1Notused
2 FDL (Field-bu s Data link L aye r) is not ok
3 Clear data command received
4 Actual value is not updated
5 Spontaneous message FIFO overflow
6 PROFIBUS ASIC is not transmitting
7 Initialising of PROFIBUS option is not ok
8Notused
9Notused
10 Not u se d
11 Not u se d
12 Fatal DPR-han dling error/Error code
during init.: Bit 0
13 Fatal DPR-han dling error/Error code
during init.: Bit 1
14 Fatal DPR-han dling error/Error code
during init.: Bit 2
15 MSB Fatal DPR-handling error/Error code
during init.: Bit 3
Explanat ion of error codes:
Depending of Bit 7 the corresponding error codes
can be seen from Bit 12-15.
Bit 7 = 1: Initialisation failure
Code
0OK
1 Init. channel not empty
2 No resp. on command "Init. SPC3
controller"
3 No resp. on comm and "No action"
4 No resp. on writing init.-data
5 No valid resp. on writing in it.-data
6 No positive resp. on w riting in it.-data
Bit 7 = 0: Run time failure
Code
0OK
1 Fatal error in warn ing channel
2 Fatal error in spontaneous channel
3 F atal error in channel for input of process
data
4 F atal error in cha nnel fo r output of process
data
5 F atal error in parameter chan ne l 1
6 F atal error in parameter chan ne l 2
7 F atal error in parameter chan ne l 3
15 Fatal error in DPR form SPC3
964 Identification
Value:
0 Manufucturer
1Devicetype
2Version
3Firmwaredateyear
4 Firmware date month
5Numberofaxes
6Profibusversion
7 Database Version
8 Power unit ID
9 BMC software ID (P632)
Function:
This parameter contains the identific ation of a Profibus
slave. This parameter is read only and only accessible
via the Profibus V1 communication.
965 Profile Number
(PROFILE NUMBER)
Value:
Profile number 1. octet Manufucturer
[3]
Profile number 2. octet
[3]
Function:
This parameter c ontains the profile number which a
Profibus slave supports. This parameter is read only
and only acc essible via the Profibus V1 communication.
MG.90.A5.02 - VLT is a registered Danfoss t rademark
36
