■ Abbreviations
English German Elaboration
ACI - Acyclical Control Interval
ALI - Application Layer Interface
ATTR - Attribute
BRCT - Broadcast
CCI - Cyclical Control Interval
CR KR Communication Reference
CRL KBL Communication Reference List
CSRD - Cyclical Send and Request Data
CT Typ Connection Type
CTW STW Control Word
DA - Destination Address
DP - Distributed Pe riphery
EIA - Electronic Industries Assoc iation: Specifiers of the EIA Standard RS 485-A
EMC EMV Electromagnetic C om patibility
EN - Event Notification
FIFO - First In First Out
HSA - Highest Station Address
Hd - Hamming distance
HPFB - High Performance Field Bus
IND - Sub ind ex
I/O E/A Input/Output
ISO - Inter national Standa rds Organizatio n
IR - Information Report
LSAP - Local Service Access Point
LSB - Least Sign ificant Bit
MSB - Most Significant Bit
MAP - Manufa cturing A u to m ation Protocol
MAV HIW Main Actual Value
MMS - Manufucturing Message Specification
MRV HSW Main Reference Value
MSAC MZAC Master-Slave connection for acyclical transmission
MSAC_SI MZAC_SI Master-Slave connectio n f or acyclical transmission with slave initiative
MSCY MSZY Master-Slave connection for cyclical transmission
MSCY_SI MSZ Y_SI M aster-Sla ve connection for cyclical trans mission with slave initiative
MULT - Multicast
OD O V Object Directory
PC - Personal C omputer
PCA PKE Parameter Characteristics
PCD PZD Process Data
PCV PKW Parameter-Characteristics-Value
PDU - Protocol Data Unit
PLC SPS Programmable Logic Control
PNU - Parameter Number
PPO - P aram e ter-Process Data Object
PVA PWE Parameter Value
RAC - Receive Acknowledged request Counter
RADR - Remote Address
RC AK Request/Response Characteristics
RCC - Rec eive Confirmed request C o un ter
RSAP - Remote Service Access Point
SAC - Send Acknowledged request Counter
SAP - Service Access Point
SCC - Send Confirmed request Counter
SPM - Spo n taneo u s Notification
STW ZSW Status Word
TRT - Target Rotation Time
VDE - Association of Germ an E lectrical Technicians
VDI - Association of German Electrical Engineers
MG.90.A5.02 - VLT is a registered Danfoss t rademark
