FCM 300 / FCD 300 / VLT
®
2800 / DP V1 PROFIBUS
Bit
(Hex)
Unit
diagnose
bit
Alarm word (p. 541)
00000001 80 Ramping
00000002 81 Automatic motor tuning
00000004 82 Start clockwise/anti-
clockwise
00000008 83 Slow down
00000010 84 Catch-up
00000020 85 Feedback high
00000040 86 Feedback low
00000080 87 Output current high
00000100 72 Output current low
00000200 73 Output frequency high
00000400 74 Output frequency low
00000800 75 Brake test ok
00001000 76 Braking max.
00002000 77 Braking
00004000 78 Quick discharge ok
00008000 79 Out of frequency ran ge
00010000 64 Not used
00020000 65 Not used
00040000 66 Not used
00080000 67 Not used
00100000 68 Not used
00200000 69 Not used
00400000 70 Not used
00800000 71 Not used
01000000 56 Not used
02000000 57 Not used
04000000 58 Not used
08000000 59 Not used
10000000 60 PB acyclic MG1
communication
20000000 61 PB acyclic MG1
communication
40000000 62 Not used
80000000 63 Not used
Bit (Hex) Alarm word (p. 953)
00000001 Connection with DP-master is not
ok
00000002 Not used
00000004 FDL (Field-bus Data Link Layer) is
not ok
00000008 Clear data command received
00000010 Actual value is not updated
00000020 Spontaneous message FIFO
overflow
00000040 PROFIBUS ASIC is not transmitting
00000080 Initialising of PROFIBU S option is
not ok
00000100 Not used
00000200 Not used
00000400 Not used
00000800 Not used
00001000 Not used
00002000 Not used
00004000 Not used
00008000 Not used
MG.90.A5.02 - VLT is a registered Danfoss t rademark
40
