FCM 300 / FCD 300 / VLT
®
2800 / DP V1 PROFIBUS
PNU
#
Parameter
description
Factory setting 4-setup Conv.
index
Data
type
302 Digital inpu t, term. 18 Sta rt Yes 0 5
303 Digital input, term. 19 Reversing Yes 0 5
304 Digital input, term. 27 Reset a nd coast
inverse
Yes 0 5
305 Digital input, term . 29 Jog Yes 0 5
307 Digital input, term. 33 No fu nc tion Ye s 0 5
308 Term. 53, analogue input voltage R eference Yes 0 5
309 Term. 53, min sc aling 0.0 V Yes -1 6
310 Term. 53, max scaling 10.0 V Yes -1 6
314 Term. 60, analogue input current No function Yes 0 5
315 Term. 60, min scaling 0.0 mA Yes -4 6
316 Term. 60, max scaling 20.0 mA Yes -4 6
317 T ime out 10 se c. Yes -1 5
318 Function after timeo ut No function Yes 0 5
319 Te rm. 42, analog ue output 0-I
MAX
=0-20mA Yes 0 5
323 Relay output Control ready Yes 0 5
327 Pulse ref./FB 5000 Hz Yes 0 7
341 Term. 46 digital output Control ready Yes 0 5
342 Term. 46 Max. pulse output 5000 Hz Yes 0 6
343 Precise stop funct ion Normal ramp stop Yes 0 5
344 Counter value 100000 pulses Yes 0 7
349 Speed comp delay 10 ms Yes -3 6
4-Setup:
’Yes ’ means that the parameter can be programmed
individually in each of the four S etups, i.e. one s ingle
parameter can have four different data values . ’No’
means that the data value will be the same in all Setups.
C
onversion index :
This number refers to a conversion figure to be used
when writing or reading via serial communication
with a frequency converter.
See Data character in Serial communic at ion
in the Design Guide.
D
ata type:
Data type shows the type and length of the telegram.
Data type Description
3 Integer 16
4 Integer 32
5Unsigned8
6Unsigned16
7Unsigned32
9Textstring
MG.90.A5.02 - VLT is a registered Danfoss t rademark
46
