Mounting adapter B
1 Mounting holes for the frequency converter. Use the
screws supplied with the adapter plate.
4Side view
2 Mounting holes for the adapter plate. Use the
screws from the VLT
®
2800.
5Back view
3Front view
Illustration 1.2 Dimensions for Mounting Adapter B, Units in mm [in]
Installation Instructions
Mounting Adapter to VLT
®
2800
VLT
®
Midi Drive FC 280
MI07F102 Danfoss A/S © 02/2016 All rights reserved.
3
