Mounting adapter C
1 Mounting holes for the frequency converter. Use the
screws supplied with the adapter plate.
4Side view
2 Mounting holes for the adapter plate. Use the
screws from the VLT
®
2800.
5Back view
3Front view
Illustration 1.3 Dimensions for Mounting Adapter C, Units in mm [in]
Installation Instructions
Mounting Adapter to VLT
®
2800
VLT
®
Midi Drive FC 280
4
Danfoss A/S © 02/2016 All rights reserved. MI07F102
