Danfoss VLT 3000 Series Introduction Guide

9
MG.50.Q2.02 – VLT is a registered Danfoss trade mark
VLT
®
3000 to 5000 converter
V
LT 3000 Series
V
LT 5000 series
800 Data read-out: Reference % 515 Data Read-Out: Reference %
801 Data read-out: Frequency 518 Data read-out: Frequency
802 Data read-out: Feedback 517 Data Read-Out: Feedbac
k
803 Data read-out: Current 520 Data read-out: Current
804 Data read-out: Torque 521 Data read-out: Torque
805 Data read-out: Power kW 522 Data read-out: Power kW
806 Data read-out: Power hp 523 Data read-out: Power hp
807 Data read-out: Energy 602 Operating data kWh counter
808 Data read-out: Output voltage 524 Data read-out: Motor voltage
809 Data read-out: DC voltage 525 Data read-out: DC voltage
810 Data read-out: Motor Therm % 526 Data Read-Out: Motor Temp
811 Data read-out: Inverter Therm % 527 Data Read-Out: VLT Temp
812 Data read-out: Digital input 528 Data read-out: Digital input
813 Data read-out: Analogue Input term. 53 529 Data Read-Out: Terminal 53; Analogue Input
814 Data read-out: Analogue Input term. 60 531 Data Read-Out: Terminal 60; Analogue Input
816 Alarm Parameters 538 Data Read-Out: Alarm Word
817 Relay 01 function 323 Relay 01, Output
818 Relay 04 function 326 Relay 04, Output
819 SAP Select 806 SAP Number Select
820 Baud rate select 801 Baud rate
821 FMS/DP Select
800 Protocol Select
1 byte PPO is not supported.
822 Minimum station delay 802 Minimum station delay
823 Bus time out 802 Bus time out
824 Time Out Function 804 Bus Time Out Function
904 PPO type select 904 PPO type select
915 Assign Parameter no.s to PCD’s write 915 PCD config. Write
916 Assign Parameter no.s to PCD’s Read 916 PCD config. Read
917 Activate Spontaneous/event Messages 917 Activate Spontaneous messages
918 Station Address 918 Station Address
927 Access to Parameter Change 927 Parameter Edit
928 Access to Process Control 928 Process Control
953 Bitstream (35) 540 Data Read-Out: Warning word
967 Control Word 967 Control Word
968 Status Word 968 Status Word
970 Set-up Selection, Programming 970 Edit Set-up Selection
971 Store data values 971 Store data values
Mapping list
