VLT
®
8000 AQUA
Conversion:
The different attributes for each parameter can be seen
in the section on factory settings. Since a parameter
value can only be transferred as a whole number, a
conversion factor must be used to transfer decimals.
E
xample:
Parameter 201: minimum frequency, conversion factor
0.1. If parameter 201 is to be set to 10 Hz, a value of
100 must be transferred, since a conversion factor of
0.1 means that the transferred value will be multiplied
by 0.1. A value of 100 will thus be understood as 10.0.
C
onversion table:
Conversion Conversion
index factor
74 3.6
2 100
110
01
-1 0.1
-2 0.01
-3 0.001
-4 0.0001
■ Process word
Th
e process word block is divided into two blocks each
of 16 bits, which always come in the sequence stated.
PCD1 PCD 2
Control telegram
(master
→ slave)
Control
word
Reference
value
Reply telegram
(slave → master)
Status
word
Given output
frequency
