■ Mechanical dimensions, motor mounting
FCD 303–315 340–480 Volt
FCD 322–330 340-480 Volt
■ Mechanical dimensions, stand alone mounting
The drawings below give the mechanical dimen-
sions. All dimensions are in mm.
FCD 303-315 380-480 Volt
FCD 322–330 380–480 Volt
