VLT
®
FCD Series
Conversion:
Under the section entitled Factory Settings the vari-
ous attributes of each parameter are displayed. As a
parameter value can only be transferred as a whole
number, a conversion factor must be used to transfer
decimals.
E
xample:
Parameter 201 Output frequency, low limit f
MIN
has a
conversion factor of 0.1. If you wish to preset the
minimum frequency to 10 Hz, the value 100 must be
transferred, as a conversion factor of 0.1 means that
the value transferred is multiplied by 0.1. The value
100 will thus be perceived as 10.0.
Conversion table
Conversion
index
Conversion
factor
73 0.1
2 100
110
01
-1 0.1
-2 0.01
-3 0.001
-4 0.0001
-5 0.00001
■ Process Words
The block of process words is divided into two
blocks of 16 bits, which always occur in the defined
sequence.
PCD 1 PCD 2
Control telegram
(master ⇒slave)
Control word Reference-
value
Control telegram
(slave⇒master)
Status word Present outp.
frequency
MG.04.A1.02 - VLT is a registered Danfoss trade mark
99
Programming
