Danfoss VLT FCD 330 Design Guide

VLT
®
FCD Series
PNU
#
Parameter
description
Factory setting 4-setup Conv.
index
Data
type
200 Output frequency range Clockwise only, 0-132 Hz Yes 0 5
201 Output frequency,
low limit f
MIN
0.0 Hz Yes -1 6
202 Output frequency,
high limit f
MAX
132 Hz Yes -1 6
203 Reference range Min ref.-Max ref. Yes 0 5
204 Minimum ref Ref
MIN
0.000 Hz Yes -3 4
205 Maximum ref Ref
MAX
50.000 Hz Yes -3 4
206 Ramp type Linear Yes 0 5
207 Ramp-up time 1 3.00 sec. Yes -2 7
208 Ramp-down time 1 3.00 sec. Yes -2 7
209 Ramp-up time 2 3.00 sec. Yes -2 7
210 Ramp-down time 2 3.00 sec. Yes -2 7
211 Jog ramp time 3.00 sec. Yes -2 7
212 Quick stop ramp-down time 3.00 sec. Yes -2 7
213 Jog frequency 10.0 Hz Yes -1 6
214 Reference function Sum Yes 0 5
215 Preset reference 1 0.00% Yes -2 3
216 Preset reference 2 0.00% Yes -2 3
217 Preset reference 3 0.00% Yes -2 3
218 Preset reference 4 0.00% Yes -2 3
219 Catch up/slow down
reference
0.00% Yes -2 6
221 Current limit 160 % Yes -1 6
223 Warn. Low current 0.0 A Yes -1 6
224 Warn. High current I
MAX
Yes -1 6
225 Warn. Low frequency 0.0 Hz Yes -1 6
226 Warn. High frequency 132.0 Hz Yes -1 6
227 Warn. Low Feedback -4000.000 Yes -3 4
228 Warn.High Feedback 4000.000 Yes -3 4
229 Frequency bypass,
bandwidth
0 Hz (OFF) Yes 0 6
230 Frequency bypass 1 0.0 Hz Yes -1 6
231 Frequency bypass 2 0.0 Hz Yes -1 6
