VLT
®
FCD Series
PNU
#
Parameter
description
Factory setting 4-setup Conv.
index
Data
type
302 Digital input, term. 18 Start Yes 0 5
303 Digital input, term. 19 Reversing Yes 0 5
304 Digital input, term. 27 Reset and coast
inverse
Yes 0 5
305 Digital input, term. 29 Jog Yes 0 5
307 Digital input, term. 33 No function Yes 0 5
308 Term. 53, analogue input voltage Reference Yes 0 5
309 Term. 53, min scaling 0.0 V Yes -1 6
310 Term. 53, max scaling 10.0 V Yes -1 6
314 Term. 60, analogue input current No function Yes 0 5
315 Term. 60, min scaling 0.0 mA Yes -4 6
316 Term. 60, max scaling 20.0 mA Yes -4 6
317 Time out 10 sec. Yes 0 5
318 Function after timeout No function Yes 0 5
319 Term. 42, analogue output 0-I
MAX
= 0-20 mA Yes 0 5
323 Relay output Control ready Yes 0 5
327 Pulse Max. 33 5000 Hz Yes 0 7
328 Pulse Max. 29 5000 Hz Yes 0 7
341 Term. 46 digital output Control ready Yes 0 5
342 Term. 46 Max. pulse output 5000 Hz Yes 0 6
343 Precise stop function Normal ramp stop Yes 0 5
344 Counter value 100000 pulses Yes 0 7
349 Speed comp delay 10 ms Yes -3 6
4-Setup:
’Ye s ’ means that the parameter can be programmed
individually in each of the four Setups, i.e. one sin-
gle parameter can have four different data values.
No’ means that the data value will be the same in all
Setups.
C
onversion index:
This number refers to a conversion figure to be used
when writing or reading via serial communication
with a frequency converter.
See
Data character in Serial communication.
D
ata type:
Data type shows the type and length of the telegram.
Data type Description
3 Integer 16
4 Integer 32
5 Unsigned 8
6 Unsigned 16
7 Unsigned 32
9 Text string
MG.04.A1.02 - VLT is a registered Danfoss trade mark
