Danfoss VLT HVAC Basic Drive - Page 13

I2 Frame
IP54 380-480 V 0.75-4.0 kW
130BC299.10
7
3
2
5
1
8
4
6
1 RS 485
2 Line in
3 Earth
4 Wire clamps
5 Motor
6 UDC
7 Relays
8 I/O
I3 Frame
IP54 380-480 V 5.5-7.5 kW
130BC201.10
1 RS 485
2 Line in
3 Earth
4 Wire clamps
5 Motor
6 UDC
7 Relays
8 I/O
Quick Guide VLT HVAC Basic Drive Quick Guide
12 MG18A302 - VLT
®
is a registered Danfoss trademark
11
