Danfoss VLT HVAC Basic Drive - Page 16

Circuit Breaker Fuse
UL Non UL UL Non UL
Bussman
n
Bussman
n
Bussman
n
Bussman
n
Max fuse
Power kW Type RK5 Type RK1 Type J Type T Type G
3 x 200 - 240 V
IP20
0.25 FRS-R-10 KTN-R10 JKS-10 JIN-10 10
0.37 FRS-R-10 KTN-R10 JKS-10 JIN-10 10
0.75 FRS-R-10 KTN-R10 JKS-10 JIN-10 10
1.5 FRS-R-10 KTN-R10 JKS-10 JIN-10 10
2.2 FRS-R-15 KTN-R15 JKS-15 JIN-15 16
3.7 FRS-R-25 KTN-R25 JKS-25 JIN-25 25
5.5 FRS-R-50 KTN-R50 JKS-50 JIN-50 50
7.5 FRS-R-50 KTN-R50 JKS-50 JIN-50 50
11 FRS-R-80 KTN-R80 JKS-80 JIN-80 65
15
Cutler-Hammer
EGE3100FFG
Moeller NZMB1-A125
FRS-R-100 KTN-R100 125
18.5 FRS-R-100 KTN-R100 125
22
Cutler-Hammer
JGE3150FFG
Moeller NZMB1-A160
FRS-R-150 KTN-R150 160
30 FRS-R-150 KTN-R150 160
37
Cutler-Hammer
JGE3200FFG
Moeller NZMB1-A200
FRS-R-200 KTN-R200 200
45 FRS-R-200 KTN-R200 200
3 x 380 - 480 V
IP20
0.37 FRS-R-10 KTS-R10 JKS-10 JJS-10 10
0.75 FRS-R-10 KTS-R10 JKS-10 JJS-10 10
1.5 FRS-R-10 KTS-R10 JKS-10 JJS-10 10
2.2 FRS-R-15 KTS-R15 JKS-15 JJS-15 16
3 FRS-R-15 KTS-R15 JKS-15 JJS-15 16
4 FRS-R-15 KTS-R15 JKS-15 JJS-15 16
5.5 FRS-R-25 KTS-R25 JKS-25 JJS-25 25
7.5 FRS-R-25 KTS-R25 JKS-25 JJS-25 25
11 FRS-R-50 KTS-R50 JKS-50 JJS-50 50
15 FRS-R-50 KTS-R50 JKS-50 JJS-50 50
18.5 FRS-R-80 KTS-R80 JKS-80 JJS-80 65
22 FRS-R-80 KTS-R80 JKS-80 JJS-80 65
30
Cutler-Hammer
EGE3125FFG
Moeller NZMB1-A125
FRS-R-80 KTS-R80 JKS-R80 JJS-R80 80
37 FRS-R-100 KTS-R100 JKS-R100 JJS-R100 100
45 FRS-R-125 KTS-R125 JKS-R125 JJS-R125 125
55
Cutler-Hammer
JGE3200FFG
Moeller NZMB1-A200
FRS-R-150 KTS-R150 JKS-R150 JJS-R150 150
75 FRS-R-200 KTS-R200 JKS-R200 JJS-R200 200
90
Cutler-Hammer
JGE3250FFG
Moeller NZMB2-A250 FRS-R-250 KTS-R250 JKS-R250 JJS-R250 250
