Frequency converter PK37 PK75 P1K5 P2K2 P3K0 P4K0 P5K5 P7K5 P11K P15K P18K P22K P30K P37K P45K P55K P75K P90K
Estimated power loss [W], Best case/typical
1)
13/15 16/21 46/57 46/58 66/83 95/118 104/13
1
159/19
8
248/27
4
353/37
9
412/45
6
475/52
3
780 893 1160 1130 1460 1780
Weight enclosure IP20kg] 2.0 2.0 2.1 3.3 3.3 3.4 4.3 4.5 7.9 7.9 9.5 9.5 24.5 24.5 24.5 36.0 36.0 51.0 Efficiency [%], Best case/Typical 1 97.8/97.
3
98.0/97
.6
97.7/97
.2
98.3/97
.9
98.2/97.
8
98.0/97.
6
98.4/98
.0
98.2/9
7.8
98.1/9
7.9
98.0/9
7.8
98.1/9
7.9
98.1/9
7.9
97.8 97.9 97.1 98.3 98.3 98.3
Output current
50°C ambient temperature
Continuous (3 x 380-440 V) [A]
1.04 1.93 3.7 4.85 6.3 8.4 10.9 14.0 20.9 28.0 34.1 38.0 48.8 58.4 72.0 74.2 102.9 123.9
Intermittent (3 x 380-440 V) [A]
1.1 2.1 4.07 5.4 6.9 9.2 12.0 15.4 23.0 30.8 37.5 41.8 53.7 64.2 79.2 81.6 113.2 136.3
Continuous (3 x 440-480 V) [A]
1.0 1.8 3.4 4.4 5.5 7.5 10.0 12.6 19.1 24.0 31.3 35.0 41.6 52.0 64.0 73.5 91.0 112.0
Intermittent (3 x 440-480 V) [A]
1.1 2.0 3.7 4.8 6.1 8.3 11.0 13.9 21.0 26.4 34.4 38.5 45.8 57.2 70.4 80.9 100.1 123.2
Quick Guide VLT HVAC Basic Drive Quick Guide
