Danfoss VLT PROFINET MCA 120 Installation Guide

1 Introduction
1.1 Purpose of the Manual
This installation guide provides information for the quick
installation of a VLT
®
PROFINET MCA 120 interface in a
VLT
®
frequency converter.
The installation guide is intended for use by qualified
personnel. Users are assumed to be familiar with the VLT
®
frequency converter, with PROFINET technology, and with
the PC or PLC that is used as a master in the system.
Read the instructions before installation and ensure that
the instructions for safe installation are observed.
VLT
®
is a registered trademark.
1.2 Additional Resources
Resources available for the frequency converters and
optional equipment:
•
The VLT
®
Operating Instructions provide the
necessary information for getting the frequency
converter up and running.
•
The VLT
®
Design Guide provides detailed
information about capabilities and functionality to
design motor control systems.
•
The VLT
®
Programming Guide provides greater
detail on working with parameters and many
application examples.
•
The VLT
®
PROFINET MCA 120 Installation Guide
provides information about installing the
PROFINET and troubleshooting.
•
The VLT
®
PROFINET MCA 120 Programming Guide
provides information about configuring the
system, controlling the frequency converter,
parameter access, programming, troubleshooting,
as well as some typical application examples.
Supplementary publications and manuals are available
from Danfoss. See www.danfoss.com/BusinessAreas/DrivesSo-
lutions/Documentations/VLT+Technical+Documentation.htm
for listings.
1.3
Product Overview
1.3.1 Intended Use
This installation guide relates to the PROFINET interface.
Ordering number:
•
130B1135 (uncoated)
•
130B1235 (conformal coated)
The PROFINET interface is designed to communicate with
any system complying with the PROFINET schema version
2.2 and 2.3 standards. PROFINET provides users with the
network tools to deploy standard Ethernet technology for
manufacturing applications while enabling internet and
enterprise connectivity.
VLT
®
PROFINET MCA 120 is intended for use with:
•
VLT
®
HVAC Drive FC 102
•
VLT
®
Refrigeration Drive FC 103
•
VLT
®
AQUA Drive FC 202
•
VLT
®
AutomationDrive FC 301/FC 302
1.3.2
Items Supplied
When the fieldbus option is not factory mounted, the
following items are supplied:
•
Fieldbus option
•
LCP cradle
•
Front covers (in various sizes)
•
Stickers
•
Accessories bag
•
Strain relief (only for A1 and A2 enclosures)
•
Installation Guide
1.4
Approvals and Certifications
More approvals and certifications are available. For more
information, contact a local partner.
Introduction
Installation Guide
2 Danfoss A/S © Rev. 07/2014 All rights reserved. MG90U402
1
1
