This document describes the DAN5TFS 60CM Built-In 5 Function Electric Oven from Daniela Appliances, an Italian-heritage brand established in 2005. Daniela Appliances, founded in 1988 as Italnova, focuses on delivering high-quality, competitively priced products. Their appliances are extensively tested and come with ISO certification.

Function Description:

The DAN5TFS oven offers five distinct cooking functions to cater to various culinary needs:

Light: This function simply turns on the oven light, which is particularly useful for cleaning the oven interior.
Defrost: Utilizing only the fan, this function circulates air inside the oven to defrost food quickly without altering its protein structure.
Fan Forced: This mode engages both the fan and the rear heating element. It's ideal for multi-layer cooking, roasting, and baking, suitable for items like cookies, meringues, and pastries, ensuring even heat distribution.
Full Grill: Designed for grilling and gratin dishes, this function requires the oven door to be half-open with control protection in position. For optimal results, it should be used at a minimum temperature of 210°C and with food placed on the top three shelf positions.
Fan Grill: This function combines the rear fan with the full grill, circulating heated air evenly throughout the oven. It's recommended for grilling meat, chicken, fish, and sausages. For best results, use a minimum temperature of 210°C and the top three shelf positions. When using this function, food should be placed on a grill inset rack to allow air circulation between the food and the tray below, eliminating the need to rotate food.

Important Technical Specifications:

While specific power consumption figures are not detailed for each function, the manual provides general electrical specifications:

Voltage: AC220V-240V (for the oven lamp).
Minimum Cross-Sectional Area (Power Cord): 4mm² for single-phase connection; 2.5mm² for three-phase connection.
Oven Lamp: 15W, Socket E14.
Fitting Dimensions (General Tolerance):
- Width: 560 +/- 1.5mm
- Height: 589 +0 - 2.5mm
Cabinet Requirements: The kitchen housing must be suitable for a built-in oven, with panels made of heat-resistant material capable of withstanding temperatures of at least 120°C. The rear panel of the cabinet must be removed for free air circulation, and the panel to which the oven is fitted should have a gap of at least 70mm at the rear. The hob must have a rear gap of at least 45mm.

Usage Features:

The manual emphasizes several key usage features and safety guidelines:

Initial Use: Before first use, the oven should be run empty at 200°C for approximately 15 minutes to burn off temporary finishes and absorbed moisture, ensuring proper ventilation during this process.
Safety:
- The appliance is not intended for use by persons with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless supervised. Children should not operate the appliance unsupervised.
- The oven and its accessible parts become hot during use; avoid touching heating elements.
- Do not use the oven door as a shelf or allow children to climb or sit on it.
- Ensure the appliance is correctly and efficiently earthed. The manufacturer disclaims responsibility for damages due to improper earthing.
- The supply cable should not be subjected to temperatures more than 50°C above ambient.
- If the supply cord is damaged, it must be replaced by authorized personnel.
- The plug or double pole switch for mains supply connection must be easily accessible after installation.
- Do not grill with the oven door open.
- Do not use the appliance as a space heater or use the base of the oven for cooking.
Installation: Installation must be carried out by a qualified person (licensed electrician or certified Daniela Appliances technician/service agent) in compliance with current regulations. The oven is secured into the cabinet using two fixing holes in the frame.
Warranty: The appliance comes with a 24-month parts and labor warranty for non-professional, domestic use, commencing from the date of purchase. Commercial warranty is 3 months. Warranty is void if not installed by a licensed technician or tradesman. Proof of purchase is required for service calls.

Maintenance Features:

Proper maintenance is crucial for extending the oven's life and ensuring safe operation:

Cleaning:
- Always unplug the oven before cleaning or performing maintenance.
- Wait until the oven has cooled before cleaning.
- DO NOT use steam cleaners, pressure cleaners, caustic oven cleaning products, abrasive chemicals, harsh solvents, wax polish, metal scrapers, steel wool, or abrasive pads on enameled, chromed, or stainless-steel surfaces, as these can cause damage, moisture build-up, or scratch/shatter the glass.
- For general cleaning, use lukewarm soapy water (and household cloudy ammonia if necessary) and a soft microfibre cloth.
- Clean after every use, especially after roasting and grilling, to prevent stubborn build-up of grease and fats.
- For the electronic programmer window and oven door, use a window washing product applied to a soft cloth.
- When cleaning stainless steel, wipe in the direction of the grain to avoid scratching.
- The inner glass is NOT removable.
- Chrome shelves, oven pan, and grill insert can be washed with detergent and hot water; a non-abrasive nylon scourer can be used for very dirty items. The oven pan/tray is dishwasher friendly.
Lamp Replacement:
- Unplug the oven before replacing the lamp to avoid electric shock.
- Wear rubber gloves.
- Unscrew the glass cover attached to the lamp holder.
- Replace with a new 15W, E14 socket bulb (AC220V-240V).
- Remount the glass cover and reconnect the appliance to the power supply.
General:
- Leave the oven door open whilst it is drying after cleaning.
- Regularly wipe the control panel with a microfibre cloth.
- The manufacturer is not responsible for damages due to lack of an earth connection.
- In case of malfunction or damage, contact Daniela Appliances Pty Ltd for repair or adjustment. Do not attempt to modify the appliance characteristics.
- Any damage caused by incorrect removal or installation of the oven door will not be covered under warranty.

The manual also includes a return policy, outlining conditions for returning goods, including restocking fees for unboxed items and charges for damaged products. It emphasizes the customer's duty of care for the product while in their possession.
