Part# Description
1 Cooking Grids (x6)
2 Cooking Grid Support Brackets (x14)
3 Chimney Cap (x1)
4 Chimney Stack (x1)
5 Hopper Handle (x1)
6 Lid Stopper (x1)
7 Main Cabinet (x1)
8 Cabinet Door Handle (x1)
9 Cabinet Door Latch (x1)
10 Power Cord Bracket (x1)
11 Support Panel (x2)
12 Support Bracket (x1)
13 Water Pan (x1)
14 Flame Tamer (x1)
15 Support Leg With Wheel (x4)
16 Grease Tray (x1)
17 Grease Tray Brackets (x2)
18 Wire Components Housing (x1)
19 Grease Exhaust Tube (x1)
20 Heat Shield (x1)
21 Meat Probe (x1)
22 Door Knob (x1)
23 ¼–20x½" Screw (x12)
24 ¼–20x⅝" Screw (x4)
25 #10–24x½" Screw (x34)
26 #10–24x⅓" Screw (x2)
NOTE: Due to ongoing product development, parts are subject to change without notice.
