Dantherm CDP 50 - Spare Parts List

49
EN
Illu-
stration
Part no. Description
1
094696 Wall bracket, CDP/CDP-T 40
094827 Wall bracket, CDP/CDP-T 50
094828 Wall bracket, CDP/CDP-T 70
2 094811 Wall mounting spacers, CDP/CDP-T 40-50-70
3 094812 Cable gland M25, CDP/CDP-T 40-50-70
4 094666 Terminal bloks on DIN rail, CDP/CDP-T 40-50-70
5 094685 Control board CDP/CDP-T 40-50-70
6 094687 Interface panel with holder CDP/CDP-T 40-50-70
7 094975 Fan capacitor CDP/CDP-T 40-50-70
8
094822 Motor capacitor, Compressor CDP/CDP-T 70
094821 Motor capacitor, Compressor CDP/CDP-T 50
094688 Motor capacitor, Compressor CDP/CDP-T 40
9
094682 Splash stop, CDP 40T
094831 Splash stop, CDP 50T
094832 Splash stop, CDP 70T
10
094693 Compressor, CDP/CDP-T 40
094825 Compressor, CDP/CDP-T 50
094826 Compressor, CDP/CDP-T 70
11
094691 Compressor accessories, CDP/CDP-T 40
094823 Compressor accessories, CDP/CDP-T 50
094824 Compressor accessories, CDP/CDP-T 70
12 094973 Magnet valve CDP/CDP-T 40-50-70
13 094665 Dry lter CDP/CDP-T 40-50-70
14
094694 Copper tubes kit, CDP/CDP-T 40
094833 Copper tubes kit, CDP/CDP-T 50
094834 Copper tubes kit, CDP/CDP-T 70
15
094683 Drip tray, CDP/CDP-T 40
094817 Drip tray, CDP/CDP-T 50
094818 Drip tray, CDP/CDP-T 70
16
094664 Front CDP 40 cpl.
094807 Front CDP 50 cpl.
094808 Front CDP 70 cpl.
17 094686 PPI lter (one size)
18
094700 Front, CDP 40T cpl.
094829 Front, CDP 50T cpl.
094830 Front, CDP 70T cpl.
19
094671 Fan assembly CDP/CDP-T 40
094815 Fan assembly CDP/CDP-T 50
094816 Fan assembly CDP/CDP-T 70
20 094669 Fan CDP/CDP-T 40-50-70
21
094670 Evaporator coil cpl., CDP/CDP-T 40
094813 Evaporator coil cpl., CDP/CDP-T 50
094814 Evaporator coil cpl, CDP/CDP-T 70
22
094684 Thermo valve, CDP/CDP-T 40
094819 Thermo valve, CDP/CDP-T 50
094820 Thermo valve, CDP/CDP-T 70
23
094667 Condenser coil, CDP/CDP-T 40
094809 Condenser coil, CDP/CDP-T 50
094810 Condenser coil, CDP/CDP-T 70
24 094697 Insulation for compressor CDP/CDP-T 40-50-70
25 094690 Harness cpl. CDP/CDP-T 40-50-70
26 094681 Plastic rivets, fastening, CDP/CDP-T 40-50-70
27 094695 Screw and lock, CDP/CDP-T 40-50-70
28 094689
Temperature, RH sensor and light diode,
CDP/CDP-T 40-50-70
Spare parts list
See illustration next page
