DAPAudio DRX-8A User Manual

14
DRX Active Series
Technical Specifications
Model Active
DRX-10BA Sub
System Type
10" Active subwoofer Speaker Cabinet
Continuous Power
600W
Frequency Response
50Hz-120Hz(- 6dB)
SPL (1W1M)
94 dB /121. 8dB Max
Transducer Low
10" woofer -2.5" Voice Coil . with ventilation
Active Crossover
HPF80Hz under analog processor
Input Connectors
L - R(COMBO/ XLR - F) / L- R Link (2 - XLR - M)
L - R Output (2 - XLR - M) Balanced (15kOhms)
Input Level
L- R Line Input 0dBu
External Connectors
Volume Control /Power on with Green LE D/Clip Limiter with
RED LED/ Ground Lift / Phase Switch / HPF80 Hz Bypass
Power Supply
110-120V/220-240V SO/60Hz
Enclosure
Painted Plywood Cabinet. Black Metal Grille Protection
Enclosure Construction
15mm plywood cabinet, glued and reinforced, resistant
black paint; metal grille, rubber foot.
Mounting
One metal standard pole-mount
Dimension (H x W x D)
325 x 465 x 421mm
Net weight
15.46kg/34.08 Ibs
Model Active
DRX-12BA Sub
System Type
12" Active subwoofer Speaker Cabinet
Continuous Power
600W
Frequency Response
47Hz - 125Hz (-6dB)
SPL (1W1M)
96 dB /123. 8dB Max
Transducer Low
12" woofer - 2.5" Voice Coil. with ventilation
Active Crossover
HPF80Hz under analog processor
Input Connectors
L - R (COMBO/ XLR - F) / L- R Link (2 - XLR - M)
L - R Output (2 - XLR - M) Balanced (15kOhms)
Input Level
L - R Line Input 0dBu
External Connectors
Volume Control/Power on with Green LED/Clip Limiter with
RED LED/ Ground Lift / Phase Switch / HPF80 Hz Bypass
Power Supply
110-120V/220-240V SO/60Hz
Enclosure
Painted Plywood Cabinet. Black Metal Grille Protection
Enclosure Construction
15mm plywood cabinet, glued and reinforced, resistant
black paint; metal grille, rubber foot.
Mounting
One metal standard pole-mount
Dimension (H x W x D)
370 x 530 x 480mm
Net weight
18.6kg/41.01 Ibs
