DAPAudio DRX-8A User Manual

17
DRX Active Series
Model
DRX-12A
System
Bi-Amp.
Continuous power
LOW: 200W / HIGH:30 W
Total harmonic distortion
LOW-input/-5dBu 100Hz, out load 40, THD<O.S%
HI-input/-5dBu 1SkHz, out load SO, THD<O.S%
S/N Ratio
LOW: > 80dBu / HI: > 65dBu
Line input Level
-5dBu ±1dBu
Input Impedance
Line 15kΩ input
Indicator
Power indicator - CLIP indicator
Power supply
110-120V-60Hz / 220-240V - 5O/60Hz
External controls
Volume - Master Switch / AC select
SPL@1m
95.6 dB / 122.2 dB (Max.)
Frequency Response
5O Hz - 20kHz - 6dB
Woofer
12" Ø 305 mm - 2" Voice Coil
Driver
1" Driver - 1" Voice Coil
Horn Coverage (H*V)
50° x 50°
Enclosure Construction
15mm plywood cabinet, glued and reinforced, resistant
black paint; metal grille, rubber foot.
Mounting
One ABS plastic standard pole-mount
Dimensions (H x W x D)
573.5 x 370.8 x 360mm
Model
DRX-15A
System
2-Way Active Vented Speaker Cabinet
Continuous power
LOW: 220W / HIGH:30 W
Total harmonic distortion
LOW-input/-3dBu 100Hz, out load 4 Ohms , THD
＜
0.5%
HI-input/-3dBu 15KHz, out load 8Ohms, THD
＜
0.5%
S/N Ratio
LOW:
＞
80dBu / HI:
＞
70dBu
Line input Level
-5dBu ± 1dBu
Input Impedance
Line 15KΩ input
Indicator
Power ,Clip,Signal
Power supply
115 V 60 Hz / 230 V 50 Hz Switchable
External controls
Volume Control / Power ON with Green LED / Clip Limiter
with Red LED/Ground Lift.
SPL@1m
96.5 dB / 123.5 dB (Max.)
Frequency Response
50Hz - 20kHz - 6dB
Woofer
15" Ø 381mm - 2" Voice Coil
Driver
1" Driver - 1" Voice Coil
Horn Coverage (H*V)
50° x 50°
Enclosure Construction
15mm plywood cabinet, glued and reinforced, resistant
black paint; metal grille, rubber foot.
Mounting
One ABS plastic standard pole-mount
Dimensions (H x W x D)
522 x 486 x 736mm
