DAPAudio DRX Active Series User Manual

15
DRX Active Series
Model Active
DRX-15BA Sub
System Type
15" Active subwoofer Speaker Cabinet
Continuous Power
600W
Frequency Response
45Hz - 125Hz (-6dB)
SPL (1W1M)
97 dB /124.8 dB Max
Transducer Low
15" woofer - 2.5" Voice Coil. with ventilation
Active Crossover
HPF80 Hz under analog processor
Input Connectors
L - R (COMBO/ XLR - F)f L- R Link(2 -XLR - M)
L - R Output (2 - XLR - M) Balanced (15kOhms)
Input Level
L - R Line Input 0dBu
External Connectors
Volume Control /Power on with Green LE D/Clip Limiter with
RED LED/ Ground Lift / Phase Switch / HPF80 Hz Bypass
Power Supply
110-120V/220 -240V SO/60Hz
Enclosure
Painted Plywood Cabinet. Black Metal Grille Protection
Enclosure Construction
15mm plywood cabinet, glued and reinforced, resistant
black paint; metal grille, rubber foot.
Mounting
One metal standard pole-mount
Dimension (H x W x D)
450 x 580 x 480mm
Net weight
22.4 kg/ 49.41 lbs
Model Active
DRX-18BA Sub
System Type
18" Active subwoofer Speaker Cabinet
Continuous Power
700W
Frequency Response
40Hz-120Hz(- 6dB)
SPL (1W1M)
98 dB /126dB Max
Transducer Low
18" woofer - 3" Voice Coil with ventilation
Active Crossover
HPF80 Hz under analog processor
Input Connectors
L - R (COMBO/ XLR - F)f L- R Link(2 -XLR - M)
L - R Output (2 - XLR - M) Balanced (15kOhms)
Input Level
L - R Line Input 0dBu
External Connectors
Volume Control /Power on with Green LE D/Clip Limiter with
RED LED/ Ground Lift / Phase Switch / HPF80 Hz Bypass
Power Supply
110-120V/220 -240V SO/60Hz
Enclosure
Painted Plywood Cabinet. Black Metal Grille Protection
Enclosure Construction
18mm plywood cabinet, glued and reinforced, resistant
black paint; metal grille, rubber foot.
Mounting
One metal standard pole-mount
Dimension (H x W x D)
535 x 661 x 515 mm
Net weight
27,4 kg/ 60.41 lbs
