DRX Active Series
Rear Panel Description
DRX-1OBA/12BA/15BA/18BA SUB
ON-OFF main power switch LINK LEFT/RIGHT ON XLR CONNECTOR
Input AC power socket with main fuse SIGNAL/LIMIT, Red LED, indicate ON status
POWER, Green LED, indicate ON status VOLUME main power amplifier control
BYPASS Switch Select High pass filter or bypass PHASE Switch Reverse the Polarity of SUB OUT
Ground Lift Switch OUT LEFT/RIGHT ON 2x XLR CONNECTOR
LINE IN RIGHT ON XLR CONNECTOR POWER SWITCH SELECTOR
LINE IN LEFT/MONO ON COMBO CONNECTOR
