11
40. Channel 2 line/phono switch
Used to set the input level for the channel 2 phono-line (51) input for either phono or line level.
41. Channel 1 line/phono switch
Used to set the input level for the channel 1 phono-line (52) input for either phono or line level.
42. Record RCA unbalanced out connectors
Use these to connect a recording device.
43. Master 3 RCA unbalanced out connectors
Use these outputs to connect an amplifier with unbalanced inputs.
44. Master 3 XLR balanced out connectors
Use these outputs to connect an amplifier with balanced inputs.
45. Master 2 RCA unbalanced out connectors
Use these outputs to connect an amplifier with unbalanced inputs.
46. Master 3 XLR balanced out connectors
Use these outputs to connect an amplifier with balanced inputs.
47. Master 1 RCA unbalanced out connectors
Use these outputs to connect an amplifier with unbalanced inputs.
48. Channel 5 RCA line input connectors
Use to connect a line level device. You can select one of two the Line inputs with the corresponding Line
select (14) button on the frontpanel.
49. Channel 4 RCA line input connectors
Use to connect a line level device. You can select one of two the Line inputs with the corresponding Line
select (14) button on the frontpanel.
50. Channel 3 RCA line input connectors
Use to connect a line level device. You can select one of two the Line inputs with the corresponding Line
select (14) button on the frontpanel.
51. Channel 2 RCA line/phono-line Inputs
Use the line input to connect a line level device. Depending on the position of the phono/line (40) switch,
you can connect either a line level device or a turntable to the phono-line input.
52. Channel 1 RCA line/phono-line Inputs
Use the line input to connect a line level device. Depending on the position of the phono/line (41) switch,
you can connect either a line level device or a turntable to the phono-line input.
53. GND screw
Use to connect the ground wire of your turntable.
