IMIX 7.1
Ordercode: D2350
Troubleshooting
DAP Audio IMIX-7.1
This troubleshooting guide is meant to help solve simple problems. If a problem occurs, carry out the steps
below in sequence until a solution is found. Once the unit operates properly, do not carry out following
steps.
1. If the device does not operate properly, unplug the device.
2. Check power from the wall, all cables, connections, etc.
3. If all of the above appears to be O.K., plug the unit in again.
4. If nothing happens after 30 seconds, unplug the device.
5. Return the device to your DAP Audio dealer.
Product Specification
Input channels
2 x Microphone, combo XLR/Jack
11 x Line, RCA
2 x Phono, RCA
1 x Phone, 3,5mm jack
Output channels
3 x Master Balanced, XLR
1 x REC output, RCA
1 x Headphones, 6.3mm Jack
Other specifiactions
Master EQ: 80Hz, 1KHz, 12KHz, -12dB / +12dB
Mic EQ: 80Hz, 1KHz, 12KHz, -12dB / +12dB
Frequency response: 20Hz - 20Khz
T.H.D.: <0.05%
Dimensions: 481 x 88 x 95 mm (LxHxD)
Power adapter: 2x 18 V~, 700 mA
Power consumption: 21 Watt
Size: 19”, 2HE
Dimensions (W x H x D): 483 x 89 x 89 mm
Net weight: 3,4 kg
Design and product specifications are subject to change without prior notice.
