IMIX 7.2 USB
Ordercode: D2352
Troubleshooting
DAP Audio IMIX-7.2 USB
This troubleshooting guide is meant to help solve simple problems. If a problem occurs, carry out the steps
below in sequence until a solution is found. Once the unit operates properly, do not carry out following
steps.
1. If the device does not operate properly, unplug the device.
2. Check power from the wall, all cables, connections, etc.
3. If all of the above appears to be O.K., plug the unit in again.
4. If nothing happens after 30 seconds, unplug the device.
5. Return the device to your DAP Audio dealer.
Product Specification
Input channels:
2 x Microphone, combo XLR/Jack
8 x Line, RCA
2 x audio interface, USB-B chassis
1 x Phone, 3,5mm jack
Output channels:
2 x Master Balanced, XLR/RCA
1 x Record, RCA
1 x Monitor, RCA
1 x Headphones, 6.3mm Jack
Display presets: CD 1, CD 2, TUNER, DVD, TV, BEAMER, PC1, PC2, DJ, AREA 2, AUX 1, AUX 2
USB interfaces: 48 KHz, 16 bit plug & play for windows and MAC
Channel EQ: 80 Hz, 1 KHz, 12 KHz, -12dB / +12dB
Mic EQ: 120 Hz, 800 Hz, 5 KHz, -12dB / +12dB
Frequency response: 20 Hz – 20 KHz
T.H.D.: <0.05%
Dimensions: 483 x 256 x 126 mm (WxHxD)
Power supply: 100-240V AC, 50/60Hz
Power consumption: 32Watt
Weight: 5,9 Kg
Design and product specifications are subject to change without prior notice.
