DAPAudio IMIX-7.2 USB User Manual

5
IMIX 7.2 USB
Ordercode: D2352
Overview
Front
Low control (mic 1/2)
Input display
High control (mic1/2)
Channel fader (channel 1-5)
Mid control (mic1/2)
VU-meter (master A/B)
Talkover on/off switch
Balance control (master A/B)
Master assign button (all channels)
Master control (master A/B)
Reverb control
Power on/off switch
Mic volume control (mic 1/2)
Monitor volume control
Mic on/off button
Mic 1 balanced input connector
Input selection switch (channel 1/2)
Channel select switch
Channel VU-meter (all channels)
Headphone level control
Low control (channel 1-5)
Aux in unbalanced mini jack input connector
High control (channel 1-5)
Headphone output connector
Mid control (channel 1-5)
Aux in unbalanced RCA input connectors
Input selection switch (channel 3/4)
Phone/line button
Input selection switch (channel 5)

DAPAudio IMIX-7.2 USB Specifications

General

Brand	DAPAudio
Model	IMIX-7.2 USB
Category	Music Mixer
Language	English
