DL250
INSTALLATION MANUAL
General Description
The DAS DL250 is a versatile 8 expandable to 16 zone security control. Its microcomputer design gives some of the most
versatile, yet easy to use features available for most security applications today. Some of the features of the DL250 include;
Partitionable up to three separate systems, dual reporting, Partial Arm (for at home monitoring), 15 user codes, internal log,
domestic dialling, dynamic battery test, plus many more. Each of the 8 zones can be programmed to be one of nine
different types including 24 Hour, Handover, Day Zone, and secondary entry. The system can be used with LCD or LED
Code Pads, key switches, or radio remote arming. Each zone is individually annunciated and can be isolated from the Code
Pad if so enabled. See page 11 for a description of all zone types. Read the OPERATOR’S MANUAL before you begin
the installation for the best overall description of how the DL250 functions. After installation of the security system, complete
the information on page 1 of the operator’s manual and explain the system operation to all security system
owners/operators.
Standard Parts List
The DL250 is shipped with the parts listed below.
QUANTITY PARTS DESCRIPTION PART #
1 MASTER CONTROL PANEL W/O CODE PAD FS4640
20 3K3 ½ WATT EOL RESISTORS EOL-33
1 TELECOM PHONE LEAD FS4596
1 INSTALLATION MANUAL IM-DL250
1 OPERATORS MANUAL OM-DL250
Optional Parts List
The following parts are available for use with the DL250.
OPTIONAL PARTS DESCRIPTION PART #
8 LED REMOTE CODE PAD FS4580
SMART 8 LED CODE PAD *(SMART BUSS COMPATIBLE) FS4672
SMART 12 LED / 4 ZONE EXPANDER REMOTE CODE PAD #(SMART BUSS ONLY) FS4673
LCD ALPHA NUMERIC DISPLAY CODE PAD *(SMART BUSS COMPATIBLE) FS4534
AC POWER SUPPLY 16.5V 1.5 AMP PLUG PACK FS4402
SMART PROGRAMMER WITH LCD DISPLAY FS4610
PROGRAMMER WITH DIGITAL NUMERIC DISPLAY FS4597
8 WAY RELAY OUTPUT MODULE #(SMART BUSS ONLY) FS4634
16 WAY VOLTAGE OUTPUT MODULE #(SMART BUSS ONLY) FS4614
16 WAY X10 VOLTAGE OUTPUT MODULE #(SMART BUSS ONLY) FS4804
12 VOLT 6.5 AMP HOUR BATTERY FS4312
* SMART BUSS COMPATIBLE - ARE PRODUCTS THAT CAN OPERATE IN EITHER BUSS PROTOCOLS. (Ref to buss
protocols in “FEATURE DEFINITIONS” on next page).
# SMART BUSS ONLY - ARE PRODUCTS THAT CAN ONLY OPERATE IN THE SMART BUSS PROTOCOLS. (Ref to
buss protocols in “FEATURE DEFINITIONS” on next page).
