LOCATION 158: TWIN TRIP ZONE SOUNDER CONTROL
Location 158 controls the audible characteristic of the DL250 for the twin trip activation refer to location 183-190 for further
detail on a twin trip zone type, Twin trip zones are also individually enabled in locations 183-190. The audible characteristic
programmed will be activated when the first trip occurs on a twin trip zone. If a second trip occurs within the period
programmed in location 191 or a continuous trip for more than 10 seconds occurs, the normal audible characteristic
programmed for that zone type will over ride any options programmed in this location. Twin Trip zones can not be
programmed for entry\exit zones. The audible characteristic will sound for the duration of the siren cut-off time programmed
in location 156. Factory default is "0" (silent characteristics).
VALUE SOUNDER CONTROL
0 SILENT
1 SIREN
2 CODE PAD SOUNDER
3 CODE PAD SOUNDER & SIREN
LOCATIONS 159-166: PROGRAMMING THE ZONE TYPES FOR ZONES 1-8
Locations 159 through 166 contain a number identifying the characteristics of zones 1 through 8. Location 159 corresponds
to zone 1 and location 166 corresponds to zone 8. These zones have been factory defaulted to the zone type shown in the
below chart. Other zone characteristics can be found in the table on the this page.
ZONE # DEFAULT CHARACTERISTICS
1 "3" = ENTRY/EXIT DELAY ZONE
2 "5" = HANDOVER ZONE
3 "5" = HANDOVER ZONE
4 - 8 "6" = INSTANT
DATA AVAILABLE ZONE TYPES
"1" DAY ZONE - When armed, a trip produces an instant alarm. When disarmed, a trip activates the
code pad sounder.
"2" 24 HOUR - A trip on a 24 Hour zone produces an instant alarm when armed or disarmed.
"3" ENTRY/EXIT - A trip will start entry delay. The lack of a trip during exit delay will enable the Auto
Home mode if so programmed.
"4" INTERIOR DELAY - A trip on Interior Delay zone will initiate an entry delay. It will be ignored
during exit delay and when disarmed . This zone type is used with the "Auto home/Instant" mode.
"5" HANDOVER - Interior zone that follows delay zones. It can be bypassed before arming, or
automatically bypassed in the "Auto home /Instant" mode if so programmed.
"6" INSTANT - Produces an instant alarm if tripped when armed. Ignored when disarmed.
"7" SECONDARY DELAY - Like an Entry/Exit zone but has its own independent delay time.
"8" FIRE - A short on a FIRE zone will create an alarm condition when the DL250 is armed or
disarmed. An open will create a Trouble condition. The code pad zone LED is steady for a fire
condition and flashing for a trouble condition. After a fire activation the # key must be pressed on
the keypad to clear the condition and reset the fire zone.
"9" KEY SWITCH - A zone attached to a momentary key switch will cause the DL250 to arm or
disarm when the zone is momentarily shorted from a sealed condition I.E. a 3.3K resister must be
used to seal the zone for the feature to work. NOTE: Check the corresponding "Special
Characteristics” for the selected Zone, If the zone programmed to operate as a key switch type
also has Partial Arm selected, I.E. a "4" in “Special Characteristics” then the key switch will then
arm/disarm Partial Mode.
LOCATIONS 167-174: ASSIGNING SPECIAL CHARACTERISTICS FOR ZONES 1-8
