16
Locations 167 - 174 are used to assign zone characteristics for zones 1 through 8. Location 167 is for zone 1 and location
174 is for zone 8. Each zone can have any or all of the following characteristics regardless of the zone type selected in
locations 159-166 excluding Fire zones, which cannot be Isolated. Factory default is "12" for each of these locations,
meaning that Zone Isolate Capability & Partial Arm is enabled, and the other characteristics are not enabled. When
Partial Arm is enabled, that zone is active in Partial mode. Remove this option from the zone(s) which are to be isolated
in Partial mode. Note: zone will not isolate in partial mode or group isolate if (8) Zone Isolate Capability is not enabled.
VALUE CHARACTERISTIC VALUE CHARACTERISTIC
0 NO FEATURE SELECTED 8 ZONE ISOLATE CAPABILITY
1 FAST LOOP RESPONSE (200ms) 9 FAST LOOP RESPONSE (200MS)
ZONE ISOLATE CAPABILITY
2 GROUP ISOLATE ZONE 10 GROUP ISOLATE ZONE
ZONE ISOLATE CAPABILITY
3 FAST LOOP RESPONSE (200MS)
GROUP ISOLATE ZONE
11 FAST LOOP RESPONSE (200MS)
GROUP ISOLATE ZONE
ZONE ISOLATE CAPABILITY
4 PARTIAL ARM ZONE (Active) 12 PARTIAL ARM ZONE (Active)
ZONE ISOLATE CAPABILITY
5 FAST LOOP RESPONSE (200MS)
PARTIAL ARM ZONE (Active)
13 FAST LOOP RESPONSE (200MS)
PARTIAL ARM ZONE (Active)
ZONE ISOLATE CAPABILITY
6 GROUP ISOLATE ZONE
PARTIAL ARM ZONE (Active)
14 GROUP ISOLATE ZONE
PARTIAL ARM ZONE (Active)
ZONE ISOLATE CAPABILITY
7 FAST LOOP RESPONSE (200MS)
GROUP ISOLATE ZONE
PARTIAL ARM ZONE (Active)
15 FAST LOOP RESPONSE (200MS)
GROUP ISOLATE ZONE
PARTIAL ARM ZONE (Active)
ZONE ISOLATE CAPABILITY
LOCATIONS 175-182: ASSIGNING AUDIBLE CHARACTERISTICS FOR Zones 1-8.
Locations 175-182 are used to assign the audible characteristics of zones 1 through 8. Location 175 is for zone 1 and
location 182 is for zone 8. Each zone can have one, or a combination of the following audible characteristics. To determine
the appropriate data for these locations, refer to the chart below and add the sum of the corresponding values to arrive at
the correct data for these locations. For all zones the factory default is "1". This means that all 8 zones will create a yelp
siren output when an alarm is created. NOTE: If a Fire zone type is selected in locations 159-166, standard fire zone
characteristics will override any selection made for a zone in this section I.E. a steady siren will be generated for a sort circuit
and a code pad sounder for an open circuit. Zones with a steady siren characteristic will over ride zones with a yelp siren
characteristic. If a chime zone is selected, then refer to locations 213 and 214 for more detail.
VALUE AUDIBLE CHARACTERISTICS VALUE AUDIBLE CHARACTERISTICS
0 SILENT ZONE 8 CHIME FEATURE
1 YELP SIREN AUDIBLE 9 YELP SIREN AUDIBLE
CHIME FEATURE
2 STEADY SIREN AUDIBLE 10 STEADY SIREN AUDIBLE
CHIME FEATURE
4
12 CODE PAD SOUNDER AUDIBLE
CHIME FEATURE
5 YELP SIREN AUDIBLE
CODE PAD SOUNDER AUDIBLE
13 YELP SIREN AUDIBLE
CODE PAD SOUNDER AUDIBLE
CHIME FEATURE
6 STEADY SIREN AUDIBLE
CODE PAD SOUNDER AUDIBLE
14 STEADY SIREN AUDIBLE
CODE PAD SOUNDER AUDIBLE
CHIME FEATURE
