17
LOCATIONS 183-190: REPORTING / SPECIAL CHARACTERISTICS FOR Zones 1-8
Locations 183-190 are used to assign communicator characteristics to individual zones 1 through 8. Location 183 is for
zone 1, and location 190 is for zone 8. Each zone can have one, or a combination of these characteristics. Factory default
for all zones is (1 + 2 = "3"). This means that each zone has Restore Reporting (Value = 1), Isolate Reporting (Value
= 2) enabled. It should be noted that these locations are used to enable individual zone report capability by zone. A
reporting code must be programmed in the appropriate location to enable overall reporting capability of Restore reports
(location 332) Isolate reports (location 334). Double EOL tamper and Twin trip zone 1 through 8 are also enabled in these
locations. Program Double EOL (Value + 4) and Twin trip (Value = 8) to enable these features. Double EOL Tamper
reports is selected in location 338.
VALUE REPORTING / SPECIAL CHARACTERISTICS VALUE REPORTING / SPECIAL CHARACTERISTICS
0 NO FEATURE SELECTED 8 TWIN TRIP ENABLE
1 RESTORE REPORTING 9 RESTORE REPORTING
TWIN TRIP ENABLE
2 ISOLATE REPORTING 10 ISOLATE REPORTING
TWIN TRIP ENABLE
3 RESTORE REPORTING
ISOLATE REPORTING
11 RESTORE REPORTING
ISOLATE REPORTING
TWIN TRIP ENABLE
4 DOUBLE EOL ENABLE 12 DOUBLE EOL REPORTING
TWIN TRIP ENABLE
5 RESTORE REPORTING
DOUBLE EOL ENABLE
13 RESTORE REPORTING
DOUBLE EOL ENABLE
TWIN TRIP ENABLE
6 ISOLATE REPORTING
DOUBLE EOL ENABLE
14 ISOLATE REPORTING
DOUBLE EOL ENABLE
TWIN TRIP ENABLE
7 RESTORE REPORTING
ISOLATE REPORTING
DOUBLE EOL ENABLE
15 RESTORE REPORTING
ISOLATE REPORTING
DOUBLE EOL ENABLE
TWIN TRIP ENABLE
TWIN TRIP:
A twin trip zone requires two trips within the time programmed in location 191 or a continuous trip for more than ten seconds
for an alarm activation. If a single trip on a twin trip zone was initiated, an alarm would only occur if any other zone has been
in alarm, still is in alarm or any other zone is tripped with in the delay time set in location 191. The DL250 may have a
combination of an audible alarm or code pad sounder after the first trip, but before the second trip, the twin trip sounder
control is programmed in location 158. Reporting can only occur after the full alarm activation. Default for these locations
will be "3" Restore + Isolate Reporting. Note: Entry/Exit zone types can NOT be set for twin trip zones.
LOCATION 191: TWIN TRIP TIME PERIOD
Location 191 contains the number of 1 minute increments in the Twin Trip Zone Time Period. The Twin Trip Zone Time
Period can be programmed in 1 minute increments from 1 to 15 minutes ("1" = 1 minute through "15" = 15 minutes). The
time programmed in this location will set the time period whereby two or more zones must trip before an alarm condition
will be registered or the one zone must trigger twice within this time period. Default is 5 minutes.
LOCATION 192: ALL ABORT ENABLE
Programming a "1" in location 192, will cause the communicator to abort its report at the end of an attempt in progress or
instantly if an attempt has not begun, if a valid code is entered. All 24 hour zones and code pad activated events will also
abort. This feature is recommended for pager dialling only. Default for this location is "0", all abort disabled.
LOCATION 193: RESERVED
LOCATION 194: RING DETECT ADJUST
Programming a (6 thru 12) in location 194 may assist, if difficulties are experienced with the DL250 answering the an
incoming call. This will make the ring detect window wider so that a grater number of exchange type and ring frequencies
can be catered for. Note: "6" is most sensitive and “12" is least sensitive. Caution must be taken when programming this
location that the DL250 dose not become to sensitive to incoming calls.
