DAS DL-250 - Page 42

42
AUXILIARY OUTPUT OPTIONS
LOCATION PAGE DESCRIPTION DATA 1 DATA 2 DATA 3 DATA 4 "DEFAULT"
220-223 22 AUX PIN #1 "0 - 0 - 1 - 2"
224-227 22 AUX PIN #2 "0 - 15 - 1 - 2"
228-231 22 AUX PIN #3 "0 - 0 - 1 - 10"
232-235 22 AUX PIN #4 "0 - 0 - 1 - 11"
236-239 23 AUXILIARY OUTPUT OPENING WINDOW "0 - 6 - 0 - 0"
240-243 24 AUXILIARY OUTPUT CLOSING WINDOW "2 - 0 - 0 - 0"
244 24 AUXILIARY OUTPUT INVERSION OPT=("0" THRU "15") "0"
245 24 AUXILIARY OUTPUT MINUTES TIMING OPT=("0" THRU "15") "0"
PROGRAMMING PARTITIONS
LOCATION PAGE DESCRIPTION DATA "DEFAULT"
246 25 COMMON AREA "1" = ENABLED, "2" ENABLED WITH OPEN/CLOSE REPORTING "0"
247 25 NUMBER OF ZONES IN PARTITION #1 SELECT THE NUMBER OF ZONES "0"
248 25 NUMBER OF ZONES IN PARTITION #2 SELECT THE NUMBER OF ZONES "0"
249-251 25 RESERVED "0"
FORMAT OVERRIDE
LOCATION PAGE DESCRIPTION DATA 1 DATA 2 DATA 3 DATA 4 "DEFAULT"
252-255 25 FORMAT OVERRIDE TABLES "0 - 0 - 0 - 0"
COMMUNICATOR CODES
LOCATION PAGE DESCRIPTION DATA 1 DATA 2 DATA 3 DATA 4 "DEFAULT"
256-259 26 ZONE #1 COMMUNICATOR CODE "3 - 0 - 1 - 5"
260-263 26 ZONE #2 COMMUNICATOR CODE "3 - 0 - 2 - 5"
264-267 26 ZONE #3 COMMUNICATOR CODE "3 - 0 - 3 - 5"
268-271 27 ZONE #4 COMMUNICATOR CODE "3 - 0 - 4 - 5"
272-275 27 ZONE #5 COMMUNICATOR CODE "3 - 0 - 5 - 5"
276-279 27 ZONE #6 COMMUNICATOR CODE "3 - 0 - 6 - 5"
280-283 27 ZONE #7 COMMUNICATOR CODE "3 - 0 - 7 - 5"
284-287 27 ZONE #8 COMMUNICATOR CODE "3 - 0 - 8 - 5"
COMMUNICATOR CODES
LOCATION PAGE DESCRIPTION DATA 1 DATA 2 DATA 3 DATA 4 "DEFAULT"
288-291 27 DURESS USER CODE 15 COM CODE "0 - 0 - 0 - 5"
292-295 27 CODE PAD (1 + 3) AUX 1 COM CODE "1 - 0 - 0 - 5"
296-299 28 CODE PAD (4 + 6) AUX 2 COM CODE "1 - 0 - 0 - 5"
300-303 28 CODE PAD (¬ + #) PANIC COM CODE "2 - 0 - 0 - 5"
304-307 28 CODE PAD TAMPER COMMUNICATOR CODE "1 - 0 - 0 - 5"
308-311 28 AUTO TEST COMMUNICATOR CODES "0 - 0 - 0 - 5"
312-315 28 FAIL TO COMMUNICATE COM CODES "1 - 0 - 0 - 5"
316-319 28 BOX TAMPER COMMUNICATOR CODES "0 - 0 - 0 - 5"
320-323 28 AC POWER FAIL COMMUNICATOR CODES "1 - 0 - 0 - 5"
324-327 29 LOW BATTERY COMMUNICATOR CODES "1 - 0 - 0 - 5"
