25
Pressing a second time will recall the program.
Under Utilities mode, press either or turn the encoder clockwise, enter into the Delete Program
mode, this will change:
Choose the Program to be deleted using the and buttons.
Press enter to delete the Program.
Pressing the buttons ate any time will exit the Delete Program mode.
Note: Locked Programs have to be unlocked before they can be deleted, this applies to Program lock
and OEM/Owner locks.
The configuration us the basic of the unit and is saved as ported of the Program information, along
with the Stereo Link setting associated with the mode chosen here. Changing this mode reconfigures
the overall routing and linking of the unit. The operation has to be confirmed as routing, linking,
delay linking and crossover band name date will be changed. The unit will also mute the Outputs to
ensure that appropriate bandwidth settings can be checked before continuing. The Output parameters
can now be changed including the routing, delay linking and band names as required.
A number of particular system configurations are possible using DSP-26. Select the configuration that
is closet to your needs and change the parameters as necessary. The configuration setting is saved as
part of the Program data when a setup is stored to a user memory.
To select the desired configuration use the and buttons or rotary encoder. This will display a
screen similar to the one shown below that asks to change the setup to the displayed configuration.
RECALL
PREV/ NEXT
1.5 Delete Program
2.1 Configuration
2. Configuration
RECALL
1 UNUSED
UTILITIES
DELETE PROS NO
ENTER TO DELETE
1 MONITORS
UTILITIES
CONFIG MONO
CHANGE TO 3 WAY ?
ENTER TO CONFIRM
OPERATION
Manual del usuario/ User´s manualDSP-26
