25
6.4 Copper Piping Internal Volume
Pipe Diameter, Volume per 100 Feet
inches of Pipe, Gallons
5/8 1.2
3/4 1.8
7/8 2.5
1-1/8 2.5
1-5/8 4.3
2-1/8 9.2
6.5 Freezing Point of Aqueous Solutions
Ethylene Glycol, Freezing Point Propylene Glycol, Freezing Point
% by Volume Degrees F. % by Volume Degree F
0 32 0 32
10 24 10 27
20 15 20 18
30 4 30 8
40 -13 40 -6
50 -33 50 -2
7.0 CONTROLS
7.1 Mini DAP II Microprocessor Control Panel
The Mini DAP II microprocessor control panel is the standard control panel on the LCS equipment.
There is a separate manual that goes into extensive detail regarding functions, features, programming
and troubleshooting.
The Mini DAP II microprocessor control panel has an entire manual dedicated to its use
and operation. This manual must be referenced to complete a thorough unit installation.
Start-up is not complete until the Mini DAP II control panel settings are established.
7.2 Optional Mini DAP® III Microprocessor Control Panel
The Mini DAP III microprocessor control panel is available as an upgrade from the Mini DAP II panel
and offers additional features including remote communications (with additional communication card
options).
The Mini DAP III microprocessor control panel has an entire manual dedicated to its use
and operation. This manual must be referenced to complete a thorough unit installation.
Start-up is not complete until the Mini DAP III control panel settings are established.
7.3 Optional DAP® III Microprocessor Control Panel
The DAP III microprocessor control panel is available as an upgrade from the Mini DAP II panel and
provides a full range of features. Only required in unique situations.
