CBX500 INSTALLATION MANUAL
5
SUPPORTED READING DEVICE MODELS
HARDWARE AND SOFTWARE COMPATIBILITY
The CBX500 can be directly connected to all of the following readers through the 25-pin
connector illustrated in Figure A.
Linear Scanners
2D Readers
DS2100N NSC
DS2400N NSC
DS4800
Matrix 210™
Matrix 300™
DS6300
DS6400
DX6400
Matrix 410™
Matrix 450™
DS8100A
DX8200A
NOTE: Not all readers support all CBX accessories. Compatibility
between the accessories and your reader depends on the reading device
application software. See the "Accessories" paragraph in your reading
device Reference Manual for the list of supported CBX Series accessories.
NOTE: CBX500 is backward compatible with DS2100N/DS2400N (black
body) model reading devices using the ADP-MM1 25-pin gender changer.
See the Gender Changer documentation for the relative CBX pinout. A
scanner software upgrade may be required to manage CBX500 accessories.
HARDWARE COMPATIBILITY ONLY (PASSIVE CONNECTIONS)
NOTE: CBX500 is backward compatible with DS4600A, and
DS1100/DS2200 10-30 Vdc model reading devices using the ADP-MM1 25-
pin gender changer. See the Gender Changer documentation for the relative
CBX500 pinout. CBX500 accessory management through device application
software is not provided for these products.

Datalogic CBX500 Specifications

General

Input voltage	10 - 30 V
Power requirements	2.5W
Display	Yes
Dimensions (WxDxH)	180 x 71 x 192 mm
Keys quantity	3 keys
Product color	Blue
Display resolution	20 x 4 pixels
International Protection (IP) code	IP56
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	0 - 90 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Weight	780 g
